SLU30CH064 SeriesSLU30CH064-48-G35Slotless BLDC Motor
Quick Facts
SLU30CH064-48-G35 Slotless BLDC Motors
SLU30CH064-48-G35 Slotless BLDC Motors
Specifications:
- 1.180 in Frame Size
- 1.42 A Rated Current
- 281.8077 oz-in Rated Torque
- 48 VDC Nominal Voltage
- 4.000 in Length
Features and Benefits:
- Extremely quick response and high acceleration
- Quiet Operation
- High power density
Specifications
Motor Specifications
| Frame Size | 1.180 in |
| Motor Type | Motor + Gearhead |
| Weight | 1.008 lbs |
| Certification | RoHS |
Motor Values (At Nominal Speed)
| Nominal Voltage | 48 VDC |
| No Load Speed | 294 RPM |
| No Load Current | 460 mA |
| Nominal Speed | 265 RPM |
| Rated Speed | 270.3 RPM |
| Rated Torque | 281.8077 oz-in |
| Rated Current | 1.42 A |
| Stall Torque | 10974.9246 oz-in |
| Stall Current | 31.1 A |
| Max. Efficiency | 75.6% |
Motor Characteristics
| Terminal Resistance | 1.545 ohm |
| Terminal Inductance | 0.3685 mH |
| Speed/Torque Gradient | 1.0621 RPM/oz-in |
| Speed Constant | 215.32 RPM/V |
Motor Mechanical Data
| Max. Radial Load | 22.48 lbf |
Motor Thermal Data
| Max winding temperature | 311.00 °F |
| Max winding temperature | 311.00 °F |
Gearhead Specifications
| Gearhead Reduction Ratio | 35 |
| Nominal Reduction Ratio | 35 |
Dimensions
| Model | DIM. A (length) in MAX |
|---|---|
| SLU30CH064-48-G35 | 4.000 in |
Performance Curve
SLU30CH064-48-G35
@48 VDC, 35:1 reduction
- Speed
- Current
- Power
- Efficiency
- Operating Area
- Maximum Continuous Torque
Generate new cureve based on different VDC
SLU30CH064 Series
Downloads
SLU30CH064-48-G35 Configured Datasheet (PDF)
