SLU30CH042 Series
SLU30CH042-24
Slotless BLDC Motor

Featured product media

Quick Facts

SLU30CH042-24 Slotless BLDC Motors

Specifications:
  • 1.180 in Frame Size
  • 1.04 A Rated Current
  • 3.3987 oz-in Rated Torque
  • 24 VDC Nominal Voltage
  • 1.650 in Length

Specifications

Motor Specifications

Frame Size1.180 in
Motor TypeMotor Only
Weight0.388 lbs

Motor Values (At Nominal Speed)

Nominal Voltage24 VDC
No Load Speed 10300 RPM
No Load Current230 mA
Nominal Speed8600 RPM
Rated Speed8600 RPM
Rated Torque3.3987 oz-in
Rated Current1.04 A
Stall Torque0.0376 oz-in
Stall Current11.7 A
Max. Efficiency79%

Motor Characteristics

Terminal Resistance2.05 ohm
Terminal Inductance0.25 mH
Speed/Torque Gradient 5.3813 RPM/oz-in
Speed Constant421 RPM/V
Mechanical Time Constant4.1 ms
Rotor Inertia0.056 oz-in²

Motor Mechanical Data

Max. Radial Load5.62 lbf

Motor Thermal Data

Max winding temperature311.00 °F
Max winding temperature311.00 °F
Thermal time constant motor850 s
Thermal time constant winding7.5 s

Performance Curve

SLU30CH042-24
@24 VDC

  • Speed
  • Current
  • Power
  • Efficiency
  • Operating Area
  • Maximum Continuous Torque

Generate new cureve based on different VDC

SLU30CH042 Series

Downloads

SLU30CH042-24 Configured Datasheet (PDF)
