SLU30CH042 Series
SLU30CH042-12
Slotless BLDC Motor

Featured product media

Quick Facts

SLU30CH042-12 Slotless BLDC Motors

Specifications:
  • 1.180 in Frame Size
  • 2.08 A Rated Current
  • 3.3987 oz-in Rated Torque
  • 12 VDC Nominal Voltage
  • 1.650 in Length

Specifications

Motor Specifications

Frame Size1.180 in
Motor TypeMotor Only
Weight0.388 lbs

Motor Values (At Nominal Speed)

Nominal Voltage12 VDC
No Load Speed 10250 RPM
No Load Current280 mA
Nominal Speed8830 RPM
Rated Speed7300 RPM
Rated Torque3.3987 oz-in
Rated Current2.08 A
Stall Torque37.7396 oz-in
Stall Current23.5 A
Max. Efficiency78.9%

Motor Characteristics

Terminal Resistance0.51 ohm
Terminal Inductance0.0625 mH
Speed/Torque Gradient 5.3671 RPM/oz-in
Speed Constant842 RPM/V
Mechanical Time Constant4.08 ms

Motor Mechanical Data

Max. Radial Load5.62 lbf

Motor Thermal Data

Max winding temperature311.00 °F
Max winding temperature311.00 °F
Thermal time constant motor1140 s
Thermal time constant winding3.8 s

Performance Curve

SLU30CH042-12
@12 VDC

  • Speed
  • Current
  • Power
  • Efficiency
  • Operating Area
  • Maximum Continuous Torque

Generate new cureve based on different VDC

SLU30CH042 Series

Downloads

SLU30CH042-12 Configured Datasheet (PDF)
