SLU26CH056 Series
SLU26CH056-24
Slotless BLDC Motor

Featured product media

Quick Facts

SLU26CH056-24 Slotless BLDC Motors

Specifications:
  • 1.020 in Frame Size
  • 1.84 A Rated Current
  • 6.3725 oz-in Rated Torque
  • 24 VDC Nominal Voltage
  • 2.200 in Length

Specifications

Motor Specifications

Frame Size1.020 in
Motor TypeMotor Only
Weight0.412 lbs

Motor Values (At Nominal Speed)

Nominal Voltage24 VDC
No Load Speed 10300 RPM
No Load Current315 mA
Nominal Speed9282 RPM
Rated Speed8630 RPM
Rated Torque6.3725 oz-in
Rated Current1.84 A
Stall Torque90.2776 oz-in
Stall Current27.9 A
Max. Efficiency88%

Motor Characteristics

Terminal Resistance0.86 ohm
Terminal Inductance0.1628 mH
Speed/Torque Gradient 2.2658 RPM/oz-in
Speed Constant418 RPM/V
Mechanical Time Constant1.48 ms
Rotor Inertia0.049 oz-in²

Motor Mechanical Data

Max. Radial Load4.608 lbf

Motor Thermal Data

Max winding temperature311.00 °F
Max winding temperature311.00 °F
Thermal time constant motor1178 s
Thermal time constant winding2.16 s

Performance Curve

SLU26CH056-24
@24 VDC

  • Speed
  • Current
  • Power
  • Efficiency
  • Operating Area
  • Maximum Continuous Torque

Generate new cureve based on different VDC

SLU26CH056 Series

Downloads

SLU26CH056-24 Configured Datasheet (PDF)
