SLU26CH040 Series
SLU26CH040-48
Slotless BLDC Motor

Featured product media

Quick Facts

SLU26CH040-48 Slotless BLDC Motors

Specifications:
  • 1.020 in Frame Size
  • 0.47 A Rated Current
  • 3.1155 oz-in Rated Torque
  • 48 VDC Nominal Voltage
  • 1.570 in Length

Specifications

Motor Specifications

Frame Size1.020 in
Motor TypeMotor Only
Weight0.287 lbs

Motor Values (At Nominal Speed)

Nominal Voltage48 VDC
No Load Speed 10517 RPM
No Load Current95.1 mA
Nominal Speed9080 RPM
Rated Speed8878 RPM
Rated Torque3.1155 oz-in
Rated Current0.47 A
Stall Torque28.6481 oz-in
Stall Current4.47 A
Max. Efficiency79.4%

Motor Characteristics

Terminal Resistance10.74 ohm
Terminal Inductance1.2902 mH
Speed/Torque Gradient 7.0948 RPM/oz-in
Speed Constant211 RPM/V
Mechanical Time Constant2.78 ms

Motor Mechanical Data

Max. Radial Load4.608 lbf

Motor Thermal Data

Max winding temperature311.00 °F
Max winding temperature311.00 °F
Thermal time constant motor851.5 s
Thermal time constant winding3.81 s

Performance Curve

SLU26CH040-48
@48 VDC

  • Speed
  • Current
  • Power
  • Efficiency
  • Operating Area
  • Maximum Continuous Torque

Generate new cureve based on different VDC

SLU26CH040 Series

Downloads

SLU26CH040-48 Configured Datasheet (PDF)
