SLU26CH040 Series
SLU26CH040-36
Slotless BLDC Motor

Featured product media

Quick Facts

SLU26CH040-36 Slotless BLDC Motors

Specifications:
  • 1.020 in Frame Size
  • 0.76 A Rated Current
  • 3.1155 oz-in Rated Torque
  • 36 VDC Nominal Voltage
  • 1.570 in Length

Specifications

Motor Specifications

Frame Size1.020 in
Motor TypeMotor Only
Weight0.287 lbs

Motor Values (At Nominal Speed)

Nominal Voltage36 VDC
No Load Speed 10430 RPM
No Load Current134 mA
Nominal Speed8980 RPM
Rated Speed8941 RPM
Rated Torque3.1155 oz-in
Rated Current0.76 A
Stall Torque30.4182 oz-in
Stall Current6.35 A
Max. Efficiency80.9%

Motor Characteristics

Terminal Resistance5.67 ohm
Terminal Inductance0.7157 mH
Speed/Torque Gradient 6.6982 RPM/oz-in
Speed Constant282.3 RPM/V
Mechanical Time Constant2.63 ms

Motor Mechanical Data

Max. Radial Load4.608 lbf

Motor Thermal Data

Max winding temperature311.00 °F
Max winding temperature311.00 °F
Thermal time constant motor851.5 s
Thermal time constant winding3.81 s

Performance Curve

SLU26CH040-36
@36 VDC

  • Speed
  • Current
  • Power
  • Efficiency
  • Operating Area
  • Maximum Continuous Torque

Generate new cureve based on different VDC

SLU26CH040 Series

Downloads

SLU26CH040-36 Configured Datasheet (PDF)
