SLU26CH040 Series
SLU26CH040-24
Slotless BLDC Motor

Featured product media

Quick Facts

SLU26CH040-24 Slotless BLDC Motors

Specifications:
  • 1.020 in Frame Size
  • 1.1 A Rated Current
  • 3.1155 oz-in Rated Torque
  • 24 VDC Nominal Voltage
  • 1.570 in Length

Specifications

Motor Specifications

Frame Size1.020 in
Motor TypeMotor Only
Weight0.287 lbs

Motor Values (At Nominal Speed)

Nominal Voltage24 VDC
No Load Speed 10220 RPM
No Load Current162 mA
Nominal Speed8710 RPM
Rated Speed8504 RPM
Rated Torque3.1155 oz-in
Rated Current1.1 A
Stall Torque28.549 oz-in
Stall Current8.76 A
Max. Efficiency79.9%

Motor Characteristics

Terminal Resistance2.74 ohm
Terminal Inductance0.328 mH
Speed/Torque Gradient 6.9956 RPM/oz-in
Speed Constant415 RPM/V
Mechanical Time Constant2.74 ms

Motor Mechanical Data

Max. Radial Load4.608 lbf

Motor Thermal Data

Max winding temperature311.00 °F
Max winding temperature311.00 °F
Thermal time constant motor851.5 s
Thermal time constant winding3.81 s

Performance Curve

SLU26CH040-24
@24 VDC

  • Speed
  • Current
  • Power
  • Efficiency
  • Operating Area
  • Maximum Continuous Torque

Generate new cureve based on different VDC

SLU26CH040 Series

Downloads

SLU26CH040-24 Configured Datasheet (PDF)
