SLU22CH032 Series
SLU22CH032-18
Slotless BLDC Motor

Featured product media

Quick Facts

SLU22CH032-18 Slotless BLDC Motors

Specifications:
  • 0.870 in Frame Size
  • 0.75 A Rated Current
  • 0.9913 oz-in Rated Torque
  • 18 VDC Nominal Voltage
  • 1.260 in Length

Specifications

Motor Specifications

Frame Size0.870 in
Motor TypeMotor Only
Weight0.157 lbs

Motor Values (At Nominal Speed)

Nominal Voltage18 VDC
No Load Speed 17850 RPM
No Load Current160 mA
Nominal Speed14580 RPM
Rated Speed14750 RPM
Rated Torque0.9913 oz-in
Rated Current0.75 A
Stall Torque8.9074 oz-in
Stall Current6.47 A
Max. Efficiency74.7%

Motor Characteristics

Terminal Resistance2.78 ohm
Terminal Inductance0.171 mH
Speed/Torque Gradient 40.2178 RPM/oz-in
Speed Constant987 RPM/V
Mechanical Time Constant5.34 ms
Rotor Inertia0.01 oz-in²

Motor Mechanical Data

Max. Radial Load3.372 lbf

Motor Thermal Data

Max winding temperature311.00 °F
Max winding temperature311.00 °F
Thermal time constant motor667 s
Thermal time constant winding1.49 s

Performance Curve

SLU22CH032-18
@18 VDC

  • Speed
  • Current
  • Power
  • Efficiency
  • Operating Area
  • Maximum Continuous Torque

Generate new cureve based on different VDC

SLU22CH032 Series

Downloads

SLU22CH032-18 Configured Datasheet (PDF)
