Featured product media

416 Series
Hybrid Stepper Motor

Features and Benefits:
  • ultimate smooth motion
  • high accuracy
Specifications:
  • NEMA 17 (1.540 in) Frame Size
  • 0.9° Step Angle
  • 0.55 to 0.7 in Length
  • 5.66 to 8.5 oz-in Holding Torque

Models

Model #NEMA sizeFrame sizeStep AngleConnection TypeLength, inCurrent AMPHolding Torque, oz-inResistanceInertia, oz-in²Weight, lbs# of LeadsAvailability
416-05-04NEMA 171.540 in0.9°Bipolar0.550 in0.6 AMP5.66 oz-in50.03 oz-in²0.201 lbs4online
416-06-05NEMA 171.540 in0.9°Bipolar0.580 in0.6 AMP7.08 oz-in4.70.04 oz-in²0.212 lbs4online
416-07-05NEMA 171.540 in0.9°Bipolar0.700 in0.6 AMP8.5 oz-in5.40.04 oz-in²0.231 lbs4online

Torque Curves

Speed

  • 416-05-04
  • 416-06-05
  • 416-07-05

Find the motor that fits your Target Torque (oz-in) and Target Speed (RPM)

Dimensions

ModelDIM. A (length) in
416-05-040.550 in
416-06-050.580 in
416-07-050.700 in

Operating Specifications

Radial Play0.001 in @ 1 lbs
End Play0.003 in @ 3 lbs
Shaft Run Out0.002 TIR
Concentricity of Mounting Pilot to Shaft0.003 TIR
Perpendicularity of Mounting Pilot to Face0.003 TIR
Max Radial Load at Dimension "K" from mounting face6 lbs
Dimension "K"0.620 in
Max Axial Load6 lbs
Maximum Case Temperature176.00 °F maximum
Ambient Temperature-4 ° to 122.00 °F
Storage Temperature-4 ° to 212.00 °F
Humidity Range (%) 85% or less, non-condensing
Magnet Wire InsulationClass B 130 deg C
Insulation Resistance100M Ohm at 500 VDC
Dielectric Strength500 VDC for 1 min

Customizations & Optimizations

Lin Engineering can ensure that your hybrid stepper motor is optimized to deliver the required performance for your specific application, whether it’s increasing torque at a specific speed range, reducing noise or vibration, or optimizing for minimal power consumption, or making specific modification  to ensure proper and native fit within your assembly.

Content image

Customization Services Include:

  • Optimized Winding
  • Multiple Shaft Options
  • Customized Leads & Connectors
  • Customized Housings & Mountings
  • Bearings & Lubricants
  • Mechatronic Solutions
  • Environmental Protection
  • Drivers & Controllers, Encoders, Gearboxes & Accessories



Learn More About Motor Customizations & Optimizations

The result is that you’ll get a motor that is fully optimized for your specific applications and configured to seamlessly fit with your assembly. This reduces your product's complexity, and increases the speed and ease of the assembly of your final product.



Speak with one of our sales representatives about your specific application needs by filling out a request for a quote.
